Audi MMI 3G High North America Bundle – K0133_3_D1 & Maps 6.24.0
Complete North American Audi MMI 3G High bundle for HNav_US_ systems. Includes HNav_US_K0133_3_D1 firmware , maps 6.24.0 / 8R0060884JE for the USA, Canada and Mexico, map activation, Green Menu script and instructions. Download or prepared SD cards available. Bose must be deselected; Bang & Olufsen is safe.
CATALOGUE ID#40541
MMI SYSTEMhnav_us
DELIVERYDigital / prepared
PRICEFrom £129.99
Check compatibilityEnter the software version shown in your MMI.
Loading security settings…
Enter and confirm a compatible MMI software version to continue.
✓
Compatibility check requiredThe basket action appears only after the entered software version matches the product rules imported from your validator.
PRODUCT INFORMATION
Audi MMI 3G High North America Bundle – K0133_3_D1 & Maps 6.24.0
CUSTOMER REVIEWS
Reviews and ratings
No approved reviews yet. Be the first to share your experience after purchase.
Sign in to leave a review. Only customers who purchased this product can submit one.
Complete Audi MMI 3G High North America Update Bundle
Update a compatible North American Audi MMI 3G High system with the latest available firmware and navigation maps for the USA, Canada and Mexico. This complete package contains:- HNav_US_K0133_3_D1 firmware
- North America maps 6.24.0
- Map database part number 8R0060884JE
- North America map activation
- Hidden Green Menu activation script
- Step-by-step installation instructions
- Download or prepared SD card delivery
Compatible MMI system
This bundle is intended exclusively for North American Audi MMI 3G High systems with a software train beginning with: HNav_US_ It is not compatible with:- HNav_EU_
- HN+_US_AU3G_
- HN+R_US_AU_
- HN+_EU_AU3G_
- HN+R_EU_AU_
- BNav_
- RMC
- MIB1, MIB2 or MIB3
- MHI2, MHI2Q, MHI3 or MH2p
How to verify compatibility
Open Version Information in the MMI settings and check the first software line. It must begin with: HNav_US_ Enter the complete current firmware version in the product field when ordering. Do not identify compatibility only by the vehicle model, production year or appearance of the navigation controls.North American region only
This package is intended for original HNav systems from:- United States
- Canada
- Mexico
Compatible Audi models
The North American HNav system was installed in selected versions of:- Audi A4, S4 and RS4 B8, approximately 2009–2012
- Audi A5, S5 and RS5 8T, approximately 2009–2012
- Audi A6, S6 and RS6 C6, approximately 2009–2011
- Audi Q5 and SQ5 8R, approximately 2009–2012
- Audi Q7 4L, approximately 2010–2012
HNav_US_K0133_3_D1 firmware
The bundle includes the latest available North American firmware for MMI 3G High: HNav_US_K0133_3_D1 / 8R0906961CP The firmware prepares the MMI for the latest available North American navigation database and can improve:- MMI stability
- Menu response
- Bluetooth pairing and reconnection
- Audio metadata synchronisation
- SiriusXM data operation
- Compatibility with newer mobile devices
- Navigation database installation
Important Bose and Bang & Olufsen information
If the vehicle has a Bose sound system, the Bose component must be deselected during the firmware update. Do not install the Bose component update. Incorrectly updating it can cause loss of sound or require additional coding or configuration. Vehicles equipped with Bang & Olufsen are safe. The Bang & Olufsen component does not need to be deselected. Verify the installed sound system before starting the firmware update.North America maps 6.24.0
The package includes the latest available navigation maps for North American MMI 3G High:- Version: 6.24.0
- Part number: 8R0060884JE
- Edition: 2021/2022
- Coverage: USA, Canada and Mexico
North America map activation included
The required North American map activation is included. After installing the 6.24.0 navigation database, run the supplied activation according to the instructions. This permanently enables the supplied maps and prevents a Map Blocked message. A separate map activation product is not required.Hidden Green Menu script included
The bundle includes a script for enabling the hidden Green Menu in MMI 3G High. If the Green Menu does not open using the standard button combination, run the supplied activation script first. The available functions and menu options are explained in our Audi MMI 3G Hidden Green Menu guide. Do not change unrelated Green Menu settings.What is included
The complete bundle contains:- HNav_US_K0133_3_D1 firmware
- North America maps 6.24.0
- North America map activation
- Hidden Green Menu activation script
- Firmware installation instructions
- Map installation instructions
- Activation instructions
- SD card preparation instructions for the download option
Delivery options
Digital download
You will receive:- Firmware files
- Navigation map files
- Map activation
- Green Menu activation script
- Preparation and installation instructions
- A computer
- Suitable SD cards
- An SD card reader
- A stable internet connection
Prepared SD cards
You will receive prepared SD cards containing:- HNav_US_K0133_3_D1 firmware
- North America maps 6.24.0
- Map activation
- Hidden Green Menu script
Installation instructions
Read the relevant instructions before starting:- How to update Audi MMI 3G firmware
- How to update maps in Audi MMI 3G High
- Audi MMI 3G Hidden Green Menu guide
- Confirm that the software train begins with HNav_US_.
- Verify whether the vehicle has Bose or Bang & Olufsen.
- Connect the vehicle to a suitable battery charger.
- Enable the hidden Green Menu if access is unavailable.
- Start the HNav_US_K0133_3_D1 firmware update.
- If the vehicle has Bose, deselect the Bose component.
- Complete and verify the firmware update.
- Install North America maps 6.24.0.
- Run the included North America activation.
- Restart the MMI.
- Verify the installed firmware and navigation database versions.
Important installation requirements
During installation:- Do not switch off the ignition or MMI.
- Do not remove an SD card during an active update.
- Do not interrupt the installation.
- Do not modify the supplied files.
- Keep the vehicle connected to a stable power source.
- Deselect Bose only when the vehicle has Bose.
- Bang & Olufsen does not require this exclusion.
- Install the firmware before the maps.
- Activate the maps only after the navigation database installation finishes.
Troubleshooting information
If error 03276 – Please Check Software Version Management appears after the update, follow our 03276 error removal guide. If error 03623 – Invalid Security appears, use the 03623 Invalid Security guide. Do not repeat interrupted updates without first identifying which installation stage failed.Frequently asked questions
Is this bundle compatible with European HNav systems?
No. It is exclusively for North American systems beginning with HNav_US_.Does the package include firmware?
Yes. HNav_US_K0133_3_D1 firmware is included.Are maps included?
Yes. North America maps 6.24.0 for the USA, Canada and Mexico are included.Is map activation included?
Yes. The required North American activation is included.Is the Green Menu activation script included?
Yes. The package contains a script for enabling the hidden Green Menu.Must Bose be deselected?
Yes. Deselect the Bose component if the vehicle has a Bose sound system.Is Bang & Olufsen safe?
Yes. Bang & Olufsen does not need to be deselected.Can I order prepared SD cards?
Yes. Choose Download or SDCARDs when ordering.Are installation instructions included?
Yes. Firmware, maps, Green Menu and activation instructions are included with both delivery options.Before ordering
Confirm that:- The current software train begins with HNav_US_.
- The vehicle is an original North American version.
- The complete current firmware has been entered in the order form.
- You know whether the vehicle has Bose or Bang & Olufsen.
- You can keep the vehicle connected to a stable power supply.
- You require the complete firmware, maps and activation package.
